VM682
Highlights
Rugged and Reliable
Dust and waterproof, rated IP67, sustaining performance in harsh environments.
Simple Intelligent Design
Easy to use, with one-touch operation for video capture, voice recording and emergency call.
Secure and Reliable Data Transfer
Dock the VM in the charger to export audio, video and other data to the EDM platform. This feature ensures the content captured remains tamper-proof and secure.
Outstanding Recording Performance
180° rotatable & 140° wide-angle lens, 16-megapixel image sensor and six infrared LED.
Slimline and Compact
This lightweight device weighs less than 170g, positioned on the person using the universal heavy duty clothing clip.
Functions
Clear Vision
Operated via one-touch in all light environments, the infrared LED supports low light with the LCD display for playback.
Data Acquisition
The MDM platform collects and stores digital evidence from the device. With intuitive Graphic User Interface (GUI), you can review, manage, and share data simply and efficiently from your PC.
Emergency Mode
Initiate an emergency call through your Hytera radio via the dedicated emergency button.
Bluetooth 4.0
Wireless connectivity for audio and BLE support.
Wi-Fi
Additional connectivity via Wi-Fi to push information and support programming.
Cabled Connections
Cable accessories are available to connect your VM685 to the Hyter Multi-mode Advanced radio or a selection of narrowband DMR and TETRA devices.
Accessories for VM682
Included as standard with VM682
Maintenance
Audio
Charger & Power
Systems that work with VM682
Technical Specifications
Size & Weight
- Dimensions (H x W x D)
- 106.5mm x 60mm x 24mm
- Weight
- 170g
- Camera
- 16 Megapixel
- Lens
- Fixed focus, all glass, 180 rotatable, diagonal 140, horizontal 106 & vertical 78
- Focus Range
- 0.1m - infinity
- Battery Life (Video Recording)
- > 8 Hours
- Battery Capacity
- 2500mAh
- Charging Time
- < 4 Hours
- Battery Dimensions
- 2.4 inch
- Screen Resolution
- 240(RGB) * 320 Dot
- Colour Type
- TFT-LCD 262k Colour Display
Memory Capacity
- Memory
- 16GB (Standard) 32GB/64GB/128GB (Optional)
Picture, Video & Sound Quality
- Video Format
- MP4
- Video Resolution
- VGA, 720p, 1080p
- Video FPS
- 30/60 fps
- Audio Format
- AAC
- Image Format
- JPG
- Image Resolution
- 4608 * 1296 (16 Megapixel), 3072 * 1728 (5 Megapixel), 2304 * 1296 (3 Megapixel)
- Pre-recording/Post-recording
- 20s / 30s
- Speaker Power
- 2W
- Microphone
- Silicon microphone x1, -38 db; Electret microphone x1, -42 db
Connections / Protection / Compatibility
- Wi-Fi
- 802.11 b/g/n (Access point and station support)
- Bluetooth
- 4.0 (Audio & BLE Support)
- Ports
- Micro USB port, 10-pn contact port
- IR Lamp
- OSRAM x6
- Night Vision Range (without light)
- 3m
- White LED
- 1 Watt x1
- Ingress Protection
- MIL-STD-810G, IP67
- Drop Protection
- 1.5m
- System Compatibility
- Windows XP/ Windows 7/ Windows 8/ Windows 10
Accessories
- Standard Accessories
- USB-cable, Charger, Clip(Rotatable, length-adjustable)
- Optional Accessories
- Shoulder epaulette, Radio Connection Cable, Multi-Charger, Wireless Remote Controller
